- Minimum Order Quantity
- Unit of Measure
- 7000 INR
- Price Range
- 7000.00 - 100000.00 INR
- Product Type
- Human Machines Interface
- Protection Level
- Frequency (MHz)
- 50/60 Hertz (HZ)
- Rated Voltage
- 24VDC / 240VAC Volt (V)
- Energy Consumption
- Depends on model & Dimensions Watt Hour (Wh)
- Output Type
- Depends on model & Dimensions
- Depends on model & Dimensions
- Depends on model & Dimensions Millimeter (mm)
- Depends on model & Dimensions Kilograms (kg)
- 12/18 Months
Delta HMI is designed to be utilized with various automation devices, machines, & equipments to assure their easy to use nature. It is highly appreciated for having large color LCD touch display that helps in assuring interactive & better interface with machine. This HMI has been precisely programmed to eliminate any error chances and assure efficient working. Delta HMI is also provided with user friendly editing software guide assuring easy maintenance.
- Supports E-Mail & FTP
- Ideal for controlling industrial robots
- Supports up to 16 languages
DOP 100 Series:
Delta HMI DOP-100 Series adopts the latest Cortex-A8 high-speed processor and display panel with high brightness, high contrast and high color. With the coming era of smart manufacturing, cloud applications are becoming more popular. For customers that are beginning to step into the cloud, DOP-100 Series features built-in Ethernet and other applicable network functions, including FTP, E-Mail, remote monitoring and control with VNC (Virtual Network Computing), and NTP (Network Time Protocols).
The DOP Series Human Machine Interface (HMI) offers fast and convenient control functions for industrial automation machines. In addition, Delta Windows-based and user-friendly DOPSoft Screen Editor and Programming Software configures the whole DOP Series. With DOPSoft, users can quickly edit images and graphs and easily set suitable communication protocol. More applications can be created, edited, downloaded and uploaded.
The DOP-W Series is a large Human Machine Interface (HMI) that comes with a high resolution and high brightness touch screen in 10.4, 12 and 15 sizes. Built-in stereo speakers increase utility and flexibility. The DOP-W Series complies with CE and UL safety approvals and provides an efficient and competitive solution to meet customer needs for a wide range of high-end industrial automation applications.
The DOP-H series handheld type HMIs feature a 7-inch high resolution LCD display for visualizing operating, monitoring and efficient control in real time. All series are equipped with built-in emergency stop switches, rear side enable switches, optional MPG (Manual Pulse Generator) and lightweight 750g design for higher flexibility and user-friendly operation. The DOP-H series is suitable for controlling industrial robots and programming the motion of robot arms and other motion control systems.
The HMC Series is a high precision control and high level performance possible, the HMC Series is equipped with two high-speed CPUs which ensure the execution efficiency and the performance of the system when running large and complicated PLC programs. Using Delta's DMCNET high speed and real time communication bus, the HMC Series is capable of connecting to the ASDA Series servo drives to provide high-performance synchronous motion control to meet the demanding requirements of high speed movement and high precision positioning.
The TP70P Series adopts a 65535 colors LCD touchscreen, supports Deltas controllers, and can be connected to all series of Deltas AC servo drives, AC motor drives, and temperature controllers. With four models providing different I/O configurations and supporting various output types, the TP70P Series high flexibility saves wiring cost and offers the best HMI and I/O control solution.
- FOB Port
- Payment Terms
- Delivery Point (DP), Cheque, Cash in Advance (CID), Cash Advance (CA), Cash on Delivery (COD), Cash Against Delivery (CAD)
- Supply Ability
- Any Not Per Month
- Delivery Time
- 2 weeks Week
- Sample Policy
- Contact us for information regarding our sample policy
- Packaging Details
- Box Packing
- Main Domestic Market
- West Bengal
- All industry standard certifications
